5998-00-764-8147 A grouping of two or more different types of electrical/electronic components mounted on a common mounting. It may include an assembly of electrical/electronic components mounted on multiple PRINTED WIRING BOARD(S) mounted back to back, stacked, and the like. The item is generally a component of a subassembly and cannot be assigned a more definite item name. Excludes items which may be identified as a subassembly. For an assembly of electrical/electronic components mounted on a single PRINTED WIRING BOARD, see CIRCUIT CARD ASSEEMBLY. Do not use if a more specific name applies.
Part Alternates: 10231818, 5998-00-764-8147, 00-764-8147, 1440007648147, 5998007648147, 007648147
Electrical and Electronic Equipment Components | Electrical and Electronic assemblies, Boards, Cards, and Associated Hardware
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 08 MAR 1968 | 00-764-8147 | 26088 ( ELECTRONIC COMPONENTS ASSEMBLY ) |
