NSN 6105-00-313-8230 GU2555ISSUE1B, 1300A, 00-313-8230
Product Details | ALTERNATING CURRENT MOTOR
6105-00-313-8230 A motor which is designed for operation from an alternating current source. See also MOTOR, CONTROL.
Part Alternates: GU2555ISSUE1B, 1300A, 6105-00-313-8230, 00-313-8230, 6105003138230, 003138230
Electric Wire, and Power and Distribution Equipment | Motors, Electrical
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 61 | 01 JAN 1963 | 00-313-8230 | 00530 ( MOTOR, ALTERNATING CURRENT ) |
Drawings & Photos | NSN 6105-00-313-8230
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 6105-00-313-8230
Related Products | NSN 6105-00-313-8230
Technical Data | NSN 6105-00-313-8230
| Characteristic | Specifications |
|---|---|
| OVERALL LENGTH | 2.939 INCHES |
| OVERALL WIDTH | 1.700 INCHES |
| LENGTH OF SHAFT FROM HOUSING | 0.562 INCHES IDENTICAL ENDS |
| MOUNTING METHOD | END BELL |
| MOUNTING FACILITY TYPE AND QUANTITY | 3 THREADED HOLE |
| MOUNTING FACILITY CIRCLE DIAMETER | 1.535 INCHES |
| INCLOSURE FEATURE | DUSTPROOF |
| INCLOSURE SPECIFICATION | COMMERCIAL |
| CURRENT RATING METHOD | LOAD |
| FREQUENCY IN HERTZ | 60.0 INPUT |
| PHASE | TWO INPUT |
| CONNECTION TYPE AND VOLTAGE RATING IN VOLTS | 175.0 LINE TO NEUTRAL SINGLE INPUT |
| TORQUE RATING AND TYPE | 2.75 INCH-OUNCES STALLED |
| WINDING TYPE | INDUCTION-SQUIRREL CAGE |
| DUTY CYCLE | CONTINUOUS |
| TEMP RATING | 110.0 AMBIENT DEG CELSIUS |
| SHAFT ROTATION DIRECTION | COUNTERCLOCKWISE IDENTICAL ENDS |
| ROTOR SPEED RATING IN RPM | 1600.0 SINGLE FULL LOAD |
| SHAFT END CHARACTERISTIC | A1 SINGLE STYLE IDENTICAL ENDS |
| SHAFT DIAMETER | 0.1560 INCHES NOMINAL IDENTICAL ENDS |
| FEATURES PROVIDED | VERTICAL MOUNTING POSITION AND HORIZONTAL MOUNTING POSITION |
| MANUFACTURERS CODE | 79172 |
| DESIGN CONTROL REFERENCE | GU2555ISSUE1B |
Restrictions/Controls & Freight Information | NSN 6105-00-313-8230
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 062120 | GENERATORS/MOTORS/PARTS NOI |
| Less than car load rating | Q | 70 |
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 593 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
