6105-01-119-0724 - TORQUE MOTOR, U306314, U3063143, U-306314-3

Product Details | TORQUE MOTOR

6105-01-119-0724 A motor whose rotating member is limited in travel to less than one mechanical revolution or travel at a speed much lower than a conventional motor. It is designed to convert an electrical energy input into a fast-responding mechanical motion output in the form of a constant torque. It does not include gear box(es) or gear train(s), commutators, brushes, or slip rings. The output torque may be exerted through a rotational travel movement or while operating in a continuously stalled or intermittently stalled condition. Excludes ELECTROMAGNETIC ACTUATOR; MOTOR, CONTROL; and SOLENOID, ELECTRICAL.

Part Alternates: U306314, U3063143, U-306314-3, 8540W10P005, 6105-01-119-0724, 01-119-0724, 6105011190724, 011190724

Electric Wire, and Power and Distribution Equipment | Motors, Electrical

Supply Group (FSG)	NSN Assign.	NIIN	Item Name Code (INC)
61	16 SEP 1981	01-119-0724	37336 ( MOTOR, TORQUE )
