NSN 6110-01-303-4669 M23928/4-06-DP, M23928406DP, MIL-P-23928/4
Product Details | POWER DISTRIBUTION PANEL
6110-01-303-4669 A panel designed for connecting, disconnecting and protecting power line feeders and/or direct control of specific electric devices such as lights, motors, electronic equipment, etc. See also FUSE BOX; SWITCH BOX; DISTRIBUTION BOX; and PANEL, POWER BUS, CIRCUIT BREAKER.
Part Alternates: M23928/4-06-DP, M23928406DP, MIL-P-23928/4, MILP239284, 6110-01-303-4669, 01-303-4669, 6110013034669, 013034669
Electric Wire, and Power and Distribution Equipment | Electrical Control Equipment
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 61 | 30 JUN 1989 | 01-303-4669 | 02794 ( PANEL, POWER DISTRIBUTION ) |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 6110-01-303-4669
Technical Data | NSN 6110-01-303-4669
| Characteristic | Specifications |
|---|---|
| INCLOSURE FEATURE | DRIPPROOF |
| PANEL QUANTITY | 1 |
| CURRENT RATING IN AMPS | 250.0 |
| INPUT VOLTAGE RATING | 125.0 AC VOLTS NOMINAL 125.0 DC VOLTS NOMINAL |
| OUTPUT VOLTAGE RATING | 125.0 AC VOLTS NOMINAL 125.0 DC VOLTS NOMINAL |
| PHASE | THREE |
| OVERALL HEIGHT | 7.130 INCHES NOMINAL |
| OVERALL WIDTH | 20.000 INCHES MAXIMUM |
| OVERALL LENGTH | 42.750 INCHES NOMINAL |
| TEST DATA DOCUMENT | 81349-MIL-P-23928 SPECIFICATION |
| SPECIFICATION/STANDARD DATA | 81349-MIL-P-23928/4 GOVERNMENT SPECIFICATION |
| MANUFACTURERS CODE | 81349 |
| NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | MIL-P-23928/4 |
| MANUFACTURERS CODE | 81349 |
| DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | M23928/4-06-DP |
Restrictions/Controls & Freight Information | NSN 6110-01-303-4669
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
