Product Details | WIRE BRAID
6145-00-191-8397 An item formed by crossing three or more electrical conductors diagonally in such a manner that each conductor passes alternately over and under one or more of the others. Manufactured in flat or tubular shapes. Refers to bulk quantities only. See also SHIELD, SPARK PLUG.
Part Alternates: MM8107, NE24336T, NEQ24336T, AA59569, A-A-59569, AA59569R36T0062, BAC31081E, BAC3108-1E, QQB575, QQB575R36T062, 087013103017, 087-013103-017, 1133224G3, 128033A, 17070032, 1707-00-32, 2162, 2163, 2250-5/64, 2250564, 36062, 425-0001-00, 4250001000, 425-0001-000, 4250001010, 425-0001-010, 95000101, 950001-01, 9502045, 950204-5, 6145-00-191-8397, 00-191-8397, 6145001918397, 425000100, 001918397
Electric Wire, and Power and Distribution Equipment | Wire and Cable, Electrical
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 61 | 01 JAN 1963 | 00-191-8397 | 00386 ( BRAID, WIRE ) |
Drawings & Photos | NSN 6145-00-191-8397
Demand History | NSN 6145-00-191-8397
Cross Reference | NSN 6145-00-191-8397
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 087-013103-017 | 26916 | NORTHROP GRUMMAN SYSTEMS CORPORATION DIV MULTIPLE |
| 1133224G3 | 28528 | ITT INDUSTRIES INC ITT AEROSPACE COMMUNICATIONS |
| 128033A | 88818 | KEARFOTT CORPORATION DBA KEARFOTT |
| 1707-00-32 | 99872 | ENTRON INDUSTRIES LIMITED PARTNERSHIP |
| 2162 | 92194 | ALPHA WIRE CORPORATION |
| 2163 | 92194 | ALPHA WIRE CORPORATION |
| 2250-5/64 | 71002 | BIRNBACH CO INC |
| 36062 | 75818 | LENZ ELECTRIC MFG CO |
| 425-0001-00 | 95105 | ROCKWELL COLLINS, INC. DIV GOVERNMENT SYSTEMS - DALLAS |
| 425-0001-000 | 95105 | ROCKWELL COLLINS, INC. DIV GOVERNMENT SYSTEMS - DALLAS |
| 425-0001-010 | 95105 | ROCKWELL COLLINS, INC. DIV GOVERNMENT SYSTEMS - DALLAS |
| 950001-01 | 80249 | BAE SYSTEMS INFORMATION AND ELECTRONIC SYSTEMS INTEGRATION INC. |
| 950204-5 | 06481 | NORTHROP GRUMMAN SYSTEMS CORPORATION |
| A-A-59569 | 58536 | FEDERAL COMMERCIAL ITEM DESCRIPTION PROMULGATED BY GENERAL SERVICES |
| AA59569R36T0062 | 58536 | FEDERAL COMMERCIAL ITEM DESCRIPTION PROMULGATED BY GENERAL SERVICES |
| BAC3108-1E | 81205 | THE BOEING COMPANY DBA BOEING |
| MM8107 | 24617 | GENERAL MOTORS CORP |
| MM8107 | 99974 | DELCO ELECTRONICS CORP DELCO SYSTEMS OPNS |
| NE24336T | 74116 | NEW ENGLAND WIRE TECHNOLOGIES CORP. |
| NEQ24336T | 74116 | NEW ENGLAND WIRE TECHNOLOGIES CORP. |
| QQB575 | 96906 | MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS |
| QQB575R36T062 | 81348 | FEDERAL SPECIFICATIONS PROMULGATED BY GENERAL SERVICES |
