Product Details | OPTICAL ELEMENT CELL
6650-01-251-2653 A cylindrical item specifically designed to hold a lens, reticle, or window in an optical system. Includes eccentric cells and/or rings designed to be rotated within the instrument to shift an optical element to a prescribed position.20512400038Optical Sighting and Ranging Equipment12700040Aircraft Gunnery Fire Control Components58550055Night Vision Equipment, Emitted and Reflected Radiation66100018Flight Instruments66500063Optical Instruments, Test Equipment, Components and Accessories
Part Alternates: 7680628, 6650-01-251-2653, 01-251-2653, 6650012512653, 012512653
Instruments and Laboratory Equipment | Optical Instruments, Test Equipment, Components and Accessories
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 66 | 15 MAR 1987 | 01-251-2653 | 21859 ( CELL, OPTICAL ELEMENT ) |
Cross Reference | NSN 6650-01-251-2653
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 7680628 | 19200 | US ARMY ARDEC RDECOM |
Request a Quote
Comments | What our customers are saying...
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Related Products | NSN 6650-01-251-2653
6650-01-251-3245, 6650-01-251-3246, 6650-01-251-3247, 6650-01-251-3370, 6650-01-251-5213
Technical Data | NSN 6650-01-251-2653
| Characteristic | Specifications |
|---|---|
| MATERIAL | BRASS, WW-T-791, GRADE 2, TYPE A |
| ECCENTRIC CONSTRUCTION | NOT PROVIDED |
| OVERALL LENGTH | 1.490 INCHES MINIMUM AND 1.510 INCHES MAXIMUM |
| OVERALL DIAMETER | 1.171 INCHES MINIMUM AND 1.172 INCHES MAXIMUM |
Restrictions/Controls & Freight Information | NSN 6650-01-251-2653
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | Q | Strategic List Item (SLI). Demilitarization not required. SLI are non-MLI(Munitions List Items) controlled by the U.S. Dept. of Commerce through the Export Administration Regulations (EAR) and indicated on the Commerce Control List (CCL). Each CCL entry is preceded by a four-digit Export Control Commerce Control List Item (CCLI) – MUT to the point of scrap required outside the United States. Inside the United States, MUT is required when the DEMIL integrity code (IC) is “3” and MUT is not required when the DEMIL IC is “6.” |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
