Product Details | NONMETALLIC SPECIAL SHAPED SECTION
9390-00-513-1694 A structural shape fabricated from nonmetallic material(s) having a peculiar preformed cross-sectional form. It may have a reinforcing agent(s) and backing. Excludes SEAL, NONMETALLIC SPECIAL SHAPED SECTION.
Part Alternates: D1427548, D1-4275-48, F455148, F-4551-48, PR1006348, PR10063-48, 9390-00-513-1694, 00-513-1694, 9390005131694, 005131694
Nonmetallic Fabricated Materials | Miscellaneous Fabricated Nonmetallic Materials
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 93 | 01 JAN 1963 | 00-513-1694 | 30219 ( NONMETALLIC SPECIAL SHAPED SECTION ) |
