Product Details | NONELECTRICAL WIRE
9505-00-684-6157 A ferrous or nonferrous wire having a solid cross section that is square or rectangular with sharp or rounded corners or edges, or is round, half-round, hexagonal, or octagonal and whose diameter, width, or greatest distance between parallel faces is less than 3/8 inch or 10.0mm. The rectangular shape is limited to a thickness less than 3/32 inch or 2.5mm and a width of 1 1/4 inch or 30.0mm or less. For dimensions greater than above, see BAR, METAL. Excludes items having electrical resistivity or conductivity ratings.2051345000065200043Dental Instruments, Equipment, and Supplies95050019Wire, Nonelectrical95250042Wire, Nonelectrical, Nonferrous Base Metal95450051Plate, Sheet, Strip, Foil, and Wire: Precious Metal
Part Alternates: ASTM A313, ASTMA313, QQW423, QQ-W-423, 39804125, 39804-125, 9505-00-684-6157, 00-684-6157, 9505006846157, 006846157
Metal Bars, Sheets, and Shapes | Wire, Nonelectrical
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 95 | 01 JAN 1961 | 00-684-6157 | 30889 ( WIRE, NONELECTRICAL ) |
Drawings & Photos | NSN 9505-00-684-6157
Demand History | NSN 9505-00-684-6157
Request a Quote
Comments | What our customers are saying...
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Related Products | NSN 9505-00-684-6157
9505-00-684-6159, 9505-00-684-6160, 9505-00-684-6161, 9505-00-684-6324, 9505-00-684-6443
Technical Data | NSN 9505-00-684-6157
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL,ASTM A313,TYPE 302 OR STEEL,ASTM A313,TYPE 304 OR STEEL,ASTM A313,TYPE 316 |
| SURFACE TREATMENT | PASSIVATED |
| HEAT TREATMENT | SPRING TEMPER |
| SURFACE CONDITION | BRIGHT OVERALL |
| MINIMUM TENSILE STRENGTH | 308000 POUNDS PER SQUARE INCH |
| MINIMUM YIELD STRENGTH | NOT RATED |
| LENGTH | 1465.000 FEET NOMINAL |
| BASIC SHAPE STYLE | D7 ROUND |
| CROSS SECTION OUTSIDE DIAMETER | 0.016 INCHES NOMINAL |
| WEIGHT PER UNIT MEASURE | ANY ACCEPTABLE |
| SPECIFICATION/STANDARD DATA | 81348-QQ-W-423/CANCELED/ GOVERNMENT SPECIFICATION |
| NONDEFINITIVE SPEC/STD DATA | I FORM AND 302 COMPOSITION OR 304 COMPOSITION OR 316 COMPOSITION AND B CONDITION |
| DEPARTURE FROM CITED DOCUMENT | AS MODIFIED BY SURFACE TREATMENT |
Restrictions/Controls & Freight Information | NSN 9505-00-684-6157
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 107480 | WIRE/BARBED WIRE I/S ACID COPPERED |
| Less than car load rating | ||
| Less than truck load rating | U | 50.0 |
| Water commodity Code | 576 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 9505-00-684-6157
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative | Purchasing | QTY UOM |
