Product Details | STRUCTURAL BEAM
9540-00-595-6701 A structural shape fabricated from a ferrous or nonferrous material and resembles the following cross-sectional forms: For the letter H, both flanges of the H section are equal or longer than the width measured along the axis of the web; for the letter I, a 16 2/3 percent slope on the inside face of the ferrous type flange, either one or both of the nonferrous type flanges are shorter than the length measured along the axis of the web; for the letters T and Z, on nonferrous type, the web is usually at right angles to the flanges. Letter H section may have a maximum of 5 percent slope on the inside face of the flanges.20295200017Structural Shapes95400040Structural Shapes, Nonferrous Base Metal
Part Alternates: AMS-QQ-A-200/3, AMSQQA2003, LS628, PA10613, QQ-A-200/3, QQA2003, T17377, 12365, 12374, 42694, 6010352, 60-10352, 9540-00-595-6701, 00-595-6701, 9540005956701, 005956701
Metal Bars, Sheets, and Shapes | Structural Shapes, Nonferrous Base Metal
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 95 | 01 JAN 1963 | 00-595-6701 | 37018 ( BEAM, STRUCTURAL ) |
Drawings & Photos | NSN 9540-00-595-6701
Demand History | NSN 9540-00-595-6701
Cross Reference | NSN 9540-00-595-6701
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 12365 | 27610 | INTERNATIONAL LIGHT METALS CORP SUB OF MARTIN MARIETTA CORP |
| 12374 | 99267 | BOHN ALUMINUM AND BRASS CO DIV OF GULF AND WESTERN MFG CO |
| 42694 | 01634 | ALUMINUM CO OF AMERICA |
| 60-10352 | 29321 | TRANSTAR METALS CORP |
| AMS-QQ-A-200/3 | 81343 | SOCIETY OF AUTOMOTIVE ENGINEERS INC |
| LS628 | 98897 | LOCKHEED MARTIN CORPORATION DBA LOCKHEED MARTIN AERONAUTICS |
| PA10613 | 06012 | TRANSTAR METALS CORP |
| QQ-A-200/3 | 81348 | FEDERAL SPECIFICATIONS PROMULGATED BY GENERAL SERVICES |
| T17377 | 03462 | HOWMET CORP WHITEHALL CASTING DIV |
Request a Quote
Comments | What our customers are saying...
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
NSNs for Compare ( up to 4 ): Add 9540-00-595-6701
Related Products | NSN 9540-00-595-6701
9540-00-595-6706, 9540-00-595-7155, 9540-00-595-7553, 9540-00-595-7757, 9540-00-595-7900
Technical Data | NSN 9540-00-595-6701
| Characteristic | Specifications |
|---|---|
| MATERIAL | ALUMINUM ALLOY AMS-QQ-A-200/3, ALLOY 2024 |
| FABRICATION METHOD | EXTRUDED |
| HEAT TREATMENT | T-3511 SOLUTION HEAT TREATED |
| LENGTH | 10.000 FEET MINIMUM AND 12.000 FEET MAXIMUM |
| BASIC SHAPE STYLE | J4 T SHAPE |
| OVERALL HEIGHT | 2.000 INCHES NOMINAL |
| LEFT SIDE TOP FLANGE THICKNESS | 0.188 INCHES NOMINAL |
| RIGHT SIDE TOP FLANGE THICKNESS | 0.188 INCHES NOMINAL |
| LEG THICKNESS | 0.188 INCHES NOMINAL |
| LEFT SIDE TOP FLANGE DISTANCE TO CENTER OF BOTH FLANGES | 1.000 INCHES NOMINAL |
| RIGHT SIDE TOP FLANGE DISTANCE TO CENTER OF BOTH FLANGES | 1.000 INCHES NOMINAL |
| FILLET RADIUS WHERE TOP LEFT FLANGE JOINS WEB FLANGE/LEG | 0.062 INCHES NOMINAL |
| FILLET RADIUS WHERE TOP RIGHT FLANGE JOINS WEB FLANGE/LEG | 0.062 INCHES NOMINAL |
| TOP FLANGE WIDTH | 2.000 INCHES NOMINAL |
| LEFT TOP INSIDE ANGLE | 85.0 DEGREES NOMINAL |
| RIGHT TOP INSIDE ANGLE | 95.0 DEGREES NOMINAL |
| FIRST TIP STYLE | 1 SQUARE END |
| SECOND TIP RELATIONSHIP TO FIRST TIP | IDENTICAL |
| THIRD TIP RELATIONSHIP TO PRECEDING TIPS | IDENTICAL W/FIRST TIP |
| WEIGHT PER UNIT MEASURE | 0.860 POUNDS PER LINEAR FOOT |
| NONDEFINITIVE SPEC/STD DATA | T3511 TEMPER |
