Product Details | FLARED TUBE FITTING CONICAL SEAL
4730-01-240-6292 A cylindrical soft metallic crush item used to seal high pressure flared tube connections. It is designed to be inserted between the conical surface of a flared tube fitting and the inner surface of the flared end of the connecting tube.
Part Alternates: AS307516, AS3075-16 , ST222916, ST2229-16 , ST228416, ST2284-16, ST228516, ST2285-16 , ST228616, ST2286-16 , 4730-01-240-6292, 01-240-6292, 4730012406292, 012406292
Pipe, Tubing, Hose, and Fittings | Hose, Pipe, Tube, Lubrication, and Railing Fittings
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 47 | 16 SEP 1986 | 01-240-6292 | 32837 ( SEAL, CONICAL, FLARED TUBE FITTING ) |
