NSN 4820-01-107-2029 E3-314-40PSI-W/10320SPRING, E331440PSIW10320SPRING, 10931

Product Details | FLUID PRESSURE REGULATING VALVE


4820-01-107-2029 A valve designed to automatically maintain within close limits a predetermined outlet pressure which may be adjustable within a specified range regardless of the higher fluctuating or constant inlet pressure. It is designed for use with compressed gas(es) and various liquids and may include gauges. It may be inline or cartridge (manifold) design. Excludes REGULATOR, PRESSURE, MEDICAL GAS ADMINISTRATION APPARATUS; REGULATOR, OXYGEN, BAROMETRIC CONTINUOUS FLOW; REGULATOR, OXYGEN DEMAND; REGULATOR, OXYGEN DILUTER DEMAND; and valve(1), fluid pressure regulating, aircraft.20248100015Valves, Powered48200018Valves, Nonpowered

Part Alternates: E3-314-40PSI-W/10320SPRING, E331440PSIW10320SPRING, 10931, 4820-01-107-2029, 01-107-2029, 4820011072029, 011072029

Valves | Valves, Nonpowered

Supply Group (FSG) NSN Assign. NIIN
48 31 JAN 1981 01-107-2029

Drawings & Photos | NSN 4820-01-107-2029




Cross Reference | NSN 4820-01-107-2029


Part Number Cage Code Manufacturer
10931 71342 IMI CASH VALVE INC
E3-314-40PSI-W/10320SPRING 71342 IMI CASH VALVE INC

Request a Quote



Comments | What our customers are saying...


Honeywell

Thank you very much for the excellent service and professional customer care.

Ernie G. Honeywell
Raytheon

The service was excellent. I can think of no improvements to date that you can make regarding internet sales.

John L. Raytheon
General Dynamics

The representative for WBParts was efficient & handled our request in a timely & professional manner.

Karen G. General Dynamics
US Airforce

Tried two other sources, neither of them responded, was all done online, never spoke to anyone.

Rex S. US Airforce
NASA

The response is quick and the price is often very good. We are completely satisfied.


NSNs for Compare ( up to 4 ): Add 4820-01-107-2029


Technical Data | NSN 4820-01-107-2029


Characteristic Specifications
BODY MATERIAL BRONZE
SEAT MATERIAL STEEL, CORROSION RESISTING
PACKING MATERIAL POLYAMIDE NYLON
FLOW CONTROL DEVICE DIAPHRAGM
FLOW CONTROL DEVICE MATERIAL RUBBER
END CONNECTION QUANTITY 2
FIRST END CONNECTION TYPE THREADED INTERNAL PIPE
FIRST END STYLE DESIGNATOR B11 PLAIN
FIRST END THREAD SIZE AND SERIES/TYPE DESIGNATOR 3/4-14 NPT
FIRST END THREAD DIRECTION RIGHT-HAND
SECOND END RELATIONSHIP WITH FIRST END IDENTICAL
BODY STYLE A1 STRAIGHT THRU
MEDIA FOR WHICH DESIGNED AIR OR WATER
REGULATION TYPE AUTOMATIC SINGLE STAGE
VALVE LOADING METHOD SPRING
REMOTE ACTUATION METHOD DIAPHRAGM
TEMP RATING 200.0 DEG FAHRENHEIT MAXIMUM
MAXIMUM INLET PRESSURE RATING 300.0 POUNDS PER SQUARE INCH
OUTLET PRESSURE SETTING 40.0 POUNDS PER SQUARE INCH
OUTLET PRESSURE RANGE 20.0 TO 70.0 POUNDS PER SQUARE INCH
OUTLET PRESSURE ACCURACY RATING NOT RATED
FILTER INCLUDED
SPECIAL FEATURES FURNISH WITH A CLEAN OUT PLUG

Restrictions/Controls & Freight Information | NSN 4820-01-107-2029


Category Code Description
Shelf-Life Code:0Nondeteriorative
Hazardous Material Indicator CodeNThere is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials
Demilitarization Code:ANon-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Controlled Inventory Item Code:UUNCLASSIFIED
Precious Metals Indicator Code:AItem does not contain precious metal
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Category Code Description
NMF Description 127220 PRESSURE REG/RED/RELIEF VALVES NOI
Less than car load rating
Less than truck load rating P 77.5
Water commodity Code 576 unknown
Originating Activity Code AX Defense Supply Center Columbus
Columbus, OH 43216-5000
Air Dimension Code A Shipment is not a consolidation and does not exceed 72 inches in any dimension.
Air Commodity B Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials.
Air Special Handling Z No special handling required.
Special Handling Code 9 unknonwn
HAZMAT
Type of Cargo Z No special type of cargo code applicable

Management | NSN 4820-01-107-2029


Category Code Description
Cognizance Codes9BNavy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Source of SupplySMSDefense Logistics Agency
Enterprise Business Systems
AgencyDNDepartment of the Navy
Service OrganizationNU.S. Navy
Acquisition Advice CodesJNOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition.
Controlled Item CodeUUNCLASSIFIED
Shelf Life Code0Nondeteriorative
Purchasing QTY
UOM
1
EA : Each
