Product Details | PLAIN CYLINDRICAL PLUG GAGE
5220-01-260-3059 A gage used for the dimensional control of the diameter of a specified hole. It consists of a gaging member or members and handle.
Part Alternates: 1C6480G02, 5220-01-260-3059, 01-260-3059, 5220012603059, 012603059
Measuring Tools | Inspection Gages and Precision Layout Tools
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 52 | 29 JUL 1987 | 01-260-3059 | 15347 ( GAGE, PLUG, PLAIN CYLINDRICAL ) |
Cross Reference | NSN 5220-01-260-3059
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 1C6480G02 | 07482 | GENERAL ELECTRIC COMPANY DBA GE |
Request a Quote
Comments | What our customers are saying...
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Related Products | NSN 5220-01-260-3059
5220-01-260-7847, 5220-01-260-7848, 5220-01-260-7849, 5220-01-260-8136, 5220-01-260-8216
Technical Data | NSN 5220-01-260-3059
| Characteristic | Specifications |
|---|---|
| SPECIAL FEATURES | CONSISTS OF GO AND NO GO GAGES,GO GAGE CONSISTS OF A BLADE AND BLOCK HELD TOGETHER BY A SCREW,WASHER AND LOCKNUT,ONE END SERVES AS A HANDLE,OTHER IS SHAPED TO FIT SLOT AND ALIGN GAGE BLADE IN SLOT,MADE OF HARDENED STEEL WITH BLACK OXIDE FINISH; NO GO GAGES CONSIST OF TWO BALLS BRAZED ON RECTANGULAR MEMBER SPACED AT A GIVEN DIMENSION WITH A ROUND HANDLE; E/I TF39-GE-1C |
| MANUFACTURERS CODE | 07482 |
| DESIGN CONTROL REFERENCE | 1C6480G02 |
