NSN 5915-00-731-8211 D11261, 0381790001, 038179-0001
Product Details | BAND PASS FILTER
5915-00-731-8211 An item designed to pass frequencies within a specified range (band) and to suppress frequencies outside the range (band). Excludes a single inductance, or a single capacitance, or a single resistance. See COIL (as modified); REACTOR; CAPACITOR (as modified); and RESISTOR (as modified).
Part Alternates: D11261, 0381790001, 038179-0001, 14563, 381791, 38179-1, 5915-00-731-8211, 00-731-8211, 5915007318211, 007318211
Electrical and Electronic Equipment Components | Filters and Networks
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 01 JAN 1961 | 00-731-8211 | 00209 ( FILTER, BAND PASS ) |
Drawings & Photos | NSN 5915-00-731-8211
Demand History | NSN 5915-00-731-8211
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5915-00-731-8211 | 2014-04-112 | 4 | DIBBS |
| 5915-00-731-8211 | 2014-04-99 | 1 | DIBBS |
| 5915-00-731-8211 | 2014-04-98 | 4 | DIBBS |
| 5915-00-731-8211 | 2014-02-36 | 2 | DIBBS |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5915-00-731-8211
Related Products | NSN 5915-00-731-8211
Technical Data | NSN 5915-00-731-8211
| Characteristic | Specifications |
|---|---|
| REFERENCE FREQUENCY PER FUNCTION | 1.0 KILOHERTZ BLANK |
| INSERTION LOSS AT REFERENCE FREQUENCY PER FUNCTION IN DECIBELS | 3.0 BLANK |
| FREQUENCY BAND WIDTH PER FUNCTION | 300.00 HERTZ BLANK AND 2.30 KILOHERTZ BLANK |
| INPUT IMPEDANCE PER FUNCTION W/LOAD | 4.0 KILOHMS BLANK |
| OUTPUT IMPEDANCE PER FUNCTION W/SOURCE ACROSS INPUT | 4.0 KILOHMS BLANK |
| INCLOSURE TYPE | ENCAPSULATED |
| FUNCTIONAL TERMINAL TYPE AND QUANTITY | 1 WIRE LEAD INPUT 1 WIRE LEAD OUTPUT 2 WIRE LEAD GROUND |
| STYLE DESIGNATOR | 2 RECTANGULAR TERMINAL/TERMINALS ON ONE SURFACE |
| OVERALL HEIGHT | 1.220 INCHES MAXIMUM |
| BODY LENGTH | 1.275 INCHES MAXIMUM |
| BODY HEIGHT | 0.840 INCHES MAXIMUM |
| BODY WIDTH | 0.900 INCHES MAXIMUM |
| MOUNTING FACILITY TYPE AND QUANTITY | 4 TERMINAL |
| DISTANCE BETWEEN CENTERLINES OF MOUNTING FACILITIES PARALLEL TO BODY LENGTH | 1.000 INCHES NOMINAL |
| DISTANCE BETWEEN CENTERLINES OF MOUNTING FACILITIES PARALLEL TO BODY WIDTH | 0.600 INCHES NOMINAL |
| III SPECIFIED FREQUENCIES OF DISCRIMINATION PER FUNCTION | 150.00 HERTZ BLANK AND 300.00 HERTZ BLANK AND 2.30 KILOHERTZ BLANK AND 3.75 KILOHERTZ BLANK |
| III DISCRIMINATION AT SPECIFIED FREQUENCIES PER FUNCTION IN DECIBELS | 15.0 MINIMUM BLANK AND 5.0 MAXIMUM BLANK AND 5.0 MAXIMUM BLANK AND 20.0 MINIMUM BLANK |
| III VIBRATION RESISTANCE RANGE IN HERTZ | 10.0 TO 55.0 |
| III OPERATING TEMP RANGE | -55.0 TO 85.0 DEG CELSIUS |
Restrictions/Controls & Freight Information | NSN 5915-00-731-8211
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 061990 | ELECTRICAL EQUIP:FILTERS |
| Less than car load rating | ||
| Less than truck load rating | P | 77.5 |
| Water commodity Code | 593 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5915-00-731-8211
Army
Navy| Category | Code | Description |
|---|---|---|
| Materiel Category and Inventory Manager | Q | Electronics Materiel (DLA/GSA Items) |
| Appropriation and Budget Activity | 2 | Stock Fund Secondary Items |
| Management Inventory Segment | 2 | NONREPARABLE ITEMS (Exclusive of Insurance and Provisioning Items). This code will be used to identify items which are not reparable. |
| Specific Group/Generic Code | Q | Avionics |
| Weapons Systems/End Item or Homogeneous Group | QA | Av VHF/UHF/AM |
| Accounting Requirements Code | X | Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DA | Department of the Army |
| Service Organization | A | U.S. Army |
| Reparability | Z | This is a nonreparable item. If condemned or economically unserviceable, then dispose at the level authorized replace the item. |
| Acquisition Advice Codes | Y | TERMINAL ITEM #(NON-STOCKED ITEMS) Future procurement is not authorized. No wholesale stock is available for issue. 1. Requisitions will not be processed to the wholesale manager. 2. Internal Service/agency requisitioning may be continued in accordance with the Service/agency requisitioning policies. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Y | TERMINAL ITEM #(NON-STOCKED ITEMS) Future procurement is not authorized. No wholesale stock is available for issue. 1. Requisitions will not be processed to the wholesale manager. 2. Internal Service/agency requisitioning may be continued in accordance with the Service/agency requisitioning policies. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
