NSN 5935-00-643-9875 MS9057629B, MS90576-29B, N3000
Product Details | CONNECTOR ADAPTER
5935-00-643-9875 An adapter with electrical contacts which provides facilities for joining two or more electrical connectors, whose design or function will not normally warrant their junction. It is not designed for permanent attachment to a cable, cord, coaxial line, or wire. The physical shape of an electrical connector should not be the determining factor of its name. Tee, angle, straight, and Y-shaped adapters are all ADAPTER, CONNECTOR. Excludes ADAPTER, CONNECTOR TO LAMPBASE; ADAPTER, LAMPHOLDER TO CONNECTOR; ADAPTER (1), CABLE CLAMP TO CONNECTOR; and ADAPTER, LAMPHOLDER. For items designed as a mechanical connection between an electrical conduit and an electrical connector, see ADAPTER (1), ELECTRICAL CONDUIT.
Part Alternates: MS9057629B, MS90576-29B, N3000, BN293700, IPC7275, RT5307600, RT53-076-00, U-29/BU, U29BU, UG-29B/U, UG29BU, W41250N6403A1, 10106094, 1PC7275, 21123315300, 2761312P1, 276-1312P1, 29B, 3841, 4101320010, 4101320-010, 4101320-10, 7275, 82101, 82-101, 9113414, 979, 5935-00-643-9875, 00-643-9875, 5935006439875, 006439875, 410132010
Electrical and Electronic Equipment Components | Connectors, Electrical
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 01 JAN 1963 | 00-643-9875 | 15091 ( ADAPTER, CONNECTOR ) |
Drawings & Photos | NSN 5935-00-643-9875
Demand History | NSN 5935-00-643-9875
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5935-00-643-9875 | 2021-08-223 | 20 | US |
| 3841 | 2012-01-30 | 40 | United States |
| 5935-00-643-9875 | 2011-04-117 | 10 | US |
Cross Reference | NSN 5935-00-643-9875
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 10106094 | 18876 | U S ARMY AVIATION AND MISSILE COMMAND |
| 1PC7275 | 74868 | AMPHENOL CORPORATION |
| 21123315300 | S0522 | TADIRAN LTD |
| 276-1312P1 | 3B150 | RAYTHEON TECHNICAL SERVICES COMPANY LLC |
| 276-1312P1 | 49956 | RAYTHEON COMPANY DBA RAYTHEON |
| 29B | 08718 | ITT CANNON ELECTRIC PHOENIX DIV |
| 3841 | 05276 | FLUKE ELECTRONICS CORP POMONA ELECTRONICS DIV |
| 4101320-010 | 82577 | RAYTHEON COMPANY DBA RAYTHEON |
| 4101320-10 | 82577 | RAYTHEON COMPANY DBA RAYTHEON |
| 7275 | 74868 | AMPHENOL CORPORATION |
| 82-101 | 74868 | AMPHENOL CORPORATION |
| 82-101 | D8311 | AMPHENOL-TUCHEL ELECTRONICS GMBH |
| 9113414 | 18876 | U S ARMY AVIATION AND MISSILE COMMAND |
| 979 | 71468 | ITT CORPORATION DBA I T T CANNON |
| BN293700 | D8796 | SPINNER GMBH |
| IPC7275 | 74868 | AMPHENOL CORPORATION |
| MS90576-29B | 96906 | MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS |
| N3000 | 94375 | AUTOMATIC CONNECTOR |
| RT53-076-00 | D2528 | ROSENBERGER HF-TECHNIK GMBH & CO. |
| U-29/BU | 80058 | JOINT ELECTRONICS TYPE DESIGNATION SYSTEM |
| UG-29B/U | 80058 | JOINT ELECTRONICS TYPE DESIGNATION SYSTEM |
| W41250N6403A1 | C0426 | AIRBUS DEFENCE AND SPACE GMBHELECTRONICS |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5935-00-643-9875
Technical Data | NSN 5935-00-643-9875
| Characteristic | Specifications |
|---|---|
| BODY STYLE | 2N STRAIGHT SHAPE, INTERNAL COUPLING |
| OVERALL LENGTH | 0.750 INCHES NOMINAL |
| OVERALL DIAMETER | 0.812 INCHES NOMINAL |
| CONNECTOR LOCKING METHOD | INTERNALLY THREADED COUPLING NUT |
| THREADED DEVICE TYPE | COUPLING FACILITY |
| THREAD SERIES DESIGNATOR | UNEF |
| NOMINAL THREAD SIZE | 0.625 INCHES |
| THREAD CLASS | 2B |
| THREAD DIRECTION | RIGHT-HAND |
| SHELL TYPE | SOLID |
| SHELL MATERIAL | COPPER ALLOY |
| SHELL SURFACE TREATMENT | SILVER |
| MATING END QUANTITY | 2 |
| CONTACT POSITION ARRANGEMENT STYLE | ABCE N ALL MATING ENDS |
| INSERT MATERIAL | PLASTIC ALL MATING ENDS |
| INCLUDED CONTACT QUANTITY | 2 ALL MATING ENDS SINGLE CONTACT GROUPING |
| CONTACT REMOVABILITY | NONREMOVABLE ALL MATING ENDS ALL CONTACT GROUPINGS |
| INCLUDED CONTACT TYPE | COAXIAL SOCKET ALL MATING ENDS ALL CONTACT GROUPINGS |
| RADIO FREQUENCY TYPE CONTACT CHARACTERISTIC IMPEDANCE IN OHMS | 50.0 ALL MATING ENDS SINGLE CONTACT GROUPING |
| CONTACT MATERIAL | COPPER ALLOY ALL MATING ENDS ALL CONTACT GROUPINGS |
| CONTACT MATERIAL DOCUMENT AND CLASSIFICATION | QQ-C-530 H FED SPEC SINGLE MATERIAL RESPONSE ALL MATING ENDS ALL CONTACT GROUPINGS |
| CONTACT SURFACE TREATMENT | SILVER ALL MATING ENDS ALL CONTACT GROUPINGS |
| III PRECIOUS MATERIAL | SILVER |
| III PRECIOUS MATERIAL AND WEIGHT | 0.010 SILVER GRAINS, TROY |
| III PRECIOUS MATERIAL AND LOCATION | CONTACT SURFACES SILVER |
| MANUFACTURERS CODE | 96906 |
| DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | MS90576-29B |
Restrictions/Controls & Freight Information | NSN 5935-00-643-9875
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | S | Item contains silver |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 061680 | ELEC WIRING PLUGS ETC |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 658 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5935-00-643-9875
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9N | Navy-owned stocks of defense electronic material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | S9E | Defense Supply Center Columbus Columbus, OH 43218 |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Y | TERMINAL ITEM #(NON-STOCKED ITEMS) Future procurement is not authorized. No wholesale stock is available for issue. 1. Requisitions will not be processed to the wholesale manager. 2. Internal Service/agency requisitioning may be continued in accordance with the Service/agency requisitioning policies. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
5 EA : Each |
