NSN 5935-01-008-5091 MS24693C51, 9225494C, 922549-4C
Product Details | CONNECTOR ADAPTER
5935-01-008-5091 An adapter with electrical contacts which provides facilities for joining two or more electrical connectors, whose design or function will not normally warrant their junction. It is not designed for permanent attachment to a cable, cord, coaxial line, or wire. The physical shape of an electrical connector should not be the determining factor of its name. Tee, angle, straight, and Y-shaped adapters are all ADAPTER, CONNECTOR. Excludes ADAPTER, CONNECTOR TO LAMPBASE; ADAPTER, LAMPHOLDER TO CONNECTOR; ADAPTER (1), CABLE CLAMP TO CONNECTOR; and ADAPTER, LAMPHOLDER. For items designed as a mechanical connection between an electrical conduit and an electrical connector, see ADAPTER (1), ELECTRICAL CONDUIT.
Part Alternates: MS24693C51, 9225494C, 922549-4C, 2080507666, 2080-5076-66, 5935-01-008-5091, 01-008-5091, 5935010085091, 010085091
Electrical and Electronic Equipment Components | Connectors, Electrical
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 25 AUG 1975 | 01-008-5091 | 15091 ( ADAPTER, CONNECTOR ) |
Drawings & Photos | NSN 5935-01-008-5091
Demand History | NSN 5935-01-008-5091
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| MS24693C51 | 2026-01-07 | 112 | United States |
| MS24693C51 | 2026-01-07 | 112 | United States |
| MS24693C51 | 2024-10-283 | 32 | Italy |
| MS24693C51 | 2021-05-138 | 4 | US |
| MS24693C51 | 2021-05-124 | 4 | IN |
| MS24693C51 | 2020-02-44 | 156 | United States |
| MS24693C51 | 2020-01-28 | 150 | CA |
| MS24693C51 | 2018-03-64 | 20 | Thailand |
| MS24693C51 | 2016-12-342 | 12 | United States |
| MS24693C51 | 2014-07-199 | 100 | United States |
| MS24693C51 | 2014-06-176 | 25 | US |
| MS24693C51 | 2013-02-42 | 6 | United States |
| MS24693C51 | 2012-11-310 | 50 | |
| MS24693C51 | 2012-05-143 | 15 | United States |
| MS24693C51 | 2011-06-166 | 30 | Italy |
| MS24693C51 | 2011-05-145 | 26 | us |
| MS24693C51 | 2011-02-46 | 4 | United States |
| MS24693C51 | 2010-12-356 | 1 | Italy |
| MS24693C51 | 2010-09-260 | 50 | Italy |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5935-01-008-5091
Technical Data | NSN 5935-01-008-5091
| Characteristic | Specifications |
|---|---|
| BODY STYLE | 8N STRAIGHT SHAPE W/FLANGE |
| OVERALL LENGTH | 1.224 INCHES MINIMUM AND 1.244 INCHES MAXIMUM |
| OVERALL HEIGHT | 0.970 INCHES MINIMUM AND 1.030 INCHES MAXIMUM |
| OVERALL WIDTH | 0.970 INCHES MINIMUM AND 1.030 INCHES MAXIMUM |
| CENTER TO CENTER DISTANCE BETWEEN MOUNTING FACILITIES PARALLEL TO HEIGHT | 0.713 INCHES MINIMUM AND 0.723 INCHES MAXIMUM |
| DISTANCE BETWEEN CENTERLINES OF MOUNTING FACILITIES PARALLEL TO BODY WIDTH | 0.713 INCHES MINIMUM AND 0.723 INCHES MAXIMUM |
| DISTANCE FROM MOUNTING SHOULDER TO FRONT FACE | 0.631 INCHES MINIMUM AND 0.651 INCHES MAXIMUM |
| UNTHREADED MOUNTING HOLE DIAMETER | 0.120 INCHES MINIMUM AND 0.130 INCHES MAXIMUM |
| CONNECTOR LOCKING METHOD | EXTERNALLY THREADED SHELL |
| THREADED DEVICE TYPE | COUPLING FACILITY |
| THREAD SERIES DESIGNATOR | UNEF AND UNS |
| NOMINAL THREAD SIZE | 0.625 INCHES AND 0.250 INCHES |
| THREAD CLASS | 2A AND 2A |
| THREAD QUANTITY PER INCH | 24 AND 36 |
| THREAD DIRECTION | RIGHT-HAND AND RIGHT-HAND |
| SHELL TYPE | SOLID |
| SHELL MATERIAL | STEEL CORROSION RESISTING |
| SHELL MATERIAL DOCUMENT AND CLASSIFICATION | QQ-S-764 FED SPEC SINGLE MATERIAL RESPONSE OR QQ-S-763,TYPE 302,303 OR 304 FED SPEC SINGLE MATERIAL RESPONSE |
| SHELL SURFACE TREATMENT | NICKEL |
| SHELL SURFACE TREATMENT DOCUMENT AND CLASSIFICATION | MIL-C-26074,CL 2 MIL SPEC SINGLE TREATMENT RESPONSE |
| MATING END QUANTITY | 2 |
| CONTACT POSITION ARRANGEMENT STYLE | ABCE N SINGLE MATING END ABDB NONSTD 1ST MATING END |
| INSERT MATERIAL | PLASTIC POLYTETRAFLUOROETHYLENE ALL MATING ENDS |
| INSERT MATERIAL DOCUMENT AND CLASSIFICATION | MIL-P-19468 MIL SPEC SINGLE MATERIAL RESPONSE ALL MATING ENDS |
| INCLUDED CONTACT QUANTITY | 1 1ST MATING END SINGLE CONTACT GROUPING 1 2ND MATING END SINGLE CONTACT GROUPING |
| CONTACT REMOVABILITY | NONREMOVABLE ALL MATING ENDS SINGLE CONTACT GROUPING |
| RADIO FREQUENCY TYPE CONTACT CHARACTERISTIC IMPEDANCE IN OHMS | 50.0 ALL MATING ENDS SINGLE CONTACT GROUPING |
| CONTACT MATERIAL | COPPER ALLOY ALL MATING ENDS SINGLE CONTACT GROUPING |
| CONTACT MATERIAL DOCUMENT AND CLASSIFICATION | QQ-C-530,COMP HT FED SPEC SINGLE MATERIAL RESPONSE ALL MATING ENDS SINGLE CONTACT GROUPING |
| CONTACT SURFACE TREATMENT | GOLD AND COPPER ALL MATING ENDS SINGLE |
