NSN 5950-00-646-5149 280339, 39745, 00-646-5149

Product Details | PULSE TRANSFORMER


5950-00-646-5149 A transformer designed to transfer pulses of nonsinusoidal wave forms between circuits without basically changing the wave forms.

Part Alternates: 280339, 39745, 5950-00-646-5149, 00-646-5149, 5950006465149, 006465149

Electrical and Electronic Equipment Components | Coils and Transformers

Supply Group (FSG) NSN Assign. NIIN
59 01 JAN 1963 00-646-5149

Drawings & Photos | NSN 5950-00-646-5149




Cross Reference | NSN 5950-00-646-5149


Part Number Cage Code Manufacturer
280339 1PQF4 L-3 COMMUNICATIONS CORPORATION DBA LINK SIMULATION & TRAINING
280339 36378 RAYTHEON TECHNICAL SERVICES COMPANY
39745 56289 SPRAGUE ELECTRIC CO WORLD HQS

Request a Quote



Comments | What our customers are saying...


Honeywell

Thank you very much for the excellent service and professional customer care.

Ernie G. Honeywell
Raytheon

The service was excellent. I can think of no improvements to date that you can make regarding internet sales.

John L. Raytheon
General Dynamics

The representative for WBParts was efficient & handled our request in a timely & professional manner.

Karen G. General Dynamics
US Airforce

Tried two other sources, neither of them responded, was all done online, never spoke to anyone.

Rex S. US Airforce
NASA

The response is quick and the price is often very good. We are completely satisfied.


NSNs for Compare ( up to 4 ): Add 5950-00-646-5149


Technical Data | NSN 5950-00-646-5149


Characteristic Specifications
TERMINAL TYPE AND QUANTITY 4 WIRE LEAD
WINDING OPERATING CURRENT 125.0 MILLIAMPERES AC MAXIMUM SINGLE COMPONENT SINGLE SECONDARY
(NON-CORE DATA) PEAK VOLTAGE RATING 300.0 VOLTS SINGLE COMPONENT SINGLE SECONDARY
INDUCTANCE RATING 1.50 MILLIHENRIES NOMINAL SINGLE COMPONENT SINGLE PRIMARY 9.00 MILLIHENRIES NOMINAL SINGLE COMPONENT SINGLE SECONDARY
IMPEDANCE RATING IN OHMS 1000.0 NOMINAL SINGLE COMPONENT SINGLE PRIMARY 6000.0 NOMINAL SINGLE COMPONENT SINGLE SECONDARY
PRIMARY TO SECONDARY TURN RATIO 2-1/2 TO 1 SINGLE COMPONENT
(NON-CORE DATA) PULSE DURATION IN MICROSECONDS 2.000 SINGLE COMPONENT
(NON-CORE DATA) PULSE RISE TIME IN MICROSECONDS 0.200 SINGLE COMPONENT
PULSE REPETITION RATE 100.0 KILOHERTZ SINGLE COMPONENT
WINDING FUNCTION AND QUANTITY 1 PRIMARY AND 1 SECONDARY SINGLE COMPONENT
MOUNTING METHOD TERMINAL SINGLE GROUP
INCLOSURE TYPE HERMETICALLY SEALED
BODY LENGTH 0.750 INCHES NOMINAL
BODY OUTSIDE DIAMETER 0.500 INCHES NOMINAL
RELIABILITY INDICATOR NOT ESTABLISHED
MANUFACTURERS CODE 56289
DESIGN CONTROL REFERENCE 39745

Restrictions/Controls & Freight Information | NSN 5950-00-646-5149


Category Code Description
Hazardous Material Indicator CodePThere is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product
Demilitarization Code:ANon-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Precious Metals Indicator Code:UPrecious metal type is unknown
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Category Code Description
NMF Description 063420 TRANSFORMERS,NOI,OR TRANSFORMER PAR
Less than car load rating
Less than truck load rating W Rating Variable
Water commodity Code 595 unknown
Originating Activity Code XX
Air Dimension Code A Shipment is not a consolidation and does not exceed 72 inches in any dimension.
Air Commodity H Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc.
Air Special Handling Z No special handling required.
Special Handling Code 9 unknonwn
HAZMAT
Type of Cargo Z No special type of cargo code applicable
