NSN 5961-00-814-2392 MS28774120, MS-28774-120 , MS28774-120
Product Details | DIODE SEMICONDUCTOR DEVICE
5961-00-814-2392 A two electrode semiconductor device having an asymmetrical voltage - current characteristic. May or may not include mounting hardware and/or heatsink. Excludes LIGHT EMITTING DIODE and SEMICONDUCTOR DEVICE,PHOTO. For items containing material such as selenium and copper oxide, see RECIFIER, METALLIC.
Part Alternates: MS28774120, MS-28774-120 , MS28774-120 , ARP568120, ARP568-120 , S1E10034PC49, S1E10041PC47 , RELEASE2663, 353-2849-00, 3532849000, 353-2849-000, 3799400 FIND 25 , 3799400FIND25, 52125 FN 82 , 52125FN82, 54947120, 54-94-7120 , 10119534, 1N689, 6390641-01 FIND 036 , 639064101FIND036, 6390641-02 FIND 036 , 639064102FIND036, 9177242, 5961-00-814-2392, 00-814-2392, 5961008142392, 008142392, 353284900
Electrical and Electronic Equipment Components | Semiconductor Devices and Associated Hardware
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 01 JAN 1962 | 00-814-2392 | 20589 ( SEMICONDUCTOR DEVICE, DIODE ) |
Drawings & Photos | NSN 5961-00-814-2392
Demand History | NSN 5961-00-814-2392
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| MS28774120 | 2024-12-360 | 10 | United States |
| MS28774120 | 2023-03-74 | 50 | United States |
| MS28774-120 | 2020-10-280 | 100 | SA |
| MS28774120 | 2016-11-323 | 8 | us |
| MS28774120 | 2013-10-287 | 50 | China |
Cross Reference | NSN 5961-00-814-2392
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 1N689 | 01281 | TRW ELECTRONICS AND DEFENSE SECTOR RF DEVICES |
| 1N689 | 03877 | GILBERT ENGINEERING CO INC/INCON SUB OF TRANSITRON ELECTRONIC CORP |
| 1N689 | 14433 | ITT SEMICONDUCTORS DIV |
| 1N689 | 14936 | GENERAL SEMICONDUCTOR INC |
| 1N689 | 16068 | INTERNATIONAL DIODE CORP |
| 1N689 | 16352 | C O D I CORP DBA CODI SEMICONDUCTOR INC |
| 1N689 | 30043 | SOLID STATE DEVICES, INC. |
| 1N689 | 31338 | SEMITRONICS CORP |
| 1N689 | 80131 | ELECTRONIC INDUSTRIES ASSOCIATION |
| 353-2849-00 | 95105 | ROCKWELL COLLINS, INC. DIV GOVERNMENT SYSTEMS - DALLAS |
| 353-2849-000 | 95105 | ROCKWELL COLLINS, INC. DIV GOVERNMENT SYSTEMS - DALLAS |
| 9177242 | 18876 | U S ARMY AVIATION AND MISSILE COMMAND |
| RELEASE2663 | 80131 | ELECTRONIC INDUSTRIES ASSOCIATION |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5961-00-814-2392
Related Products | NSN 5961-00-814-2392
Technical Data | NSN 5961-00-814-2392
| Characteristic | Specifications |
|---|---|
| SEMICONDUCTOR MATERIAL | SILICON |
| VOLTAGE RATING IN VOLTS PER CHARACTERISTIC | 600.0 MAXIMUM REVERSE VOLTAGE, PEAK |
| CURRENT RATING PER CHARACTERISTIC | 0.15 AMPERES MAXIMUM AVERAGE FORWARD CURRENT AVERAGED OVER A FULL 60-HZ CYCLE |
| MAXIMUM OPERATING TEMP PER MEASUREMENT POINT | 175.0 DEG CELSIUS AMBIENT AIR |
| INCLOSURE MATERIAL | GLASS |
| MOUNTING METHOD | TERMINAL |
| TERMINAL LENGTH | 1.000 INCHES MINIMUM |
| TERMINAL TYPE AND QUANTITY | 2 UNINSULATED WIRE LEAD |
| OVERALL LENGTH | 0.230 INCHES MINIMUM AND 0.300 INCHES MAXIMUM |
| OVERALL DIAMETER | 0.085 INCHES MINIMUM AND 0.107 INCHES MAXIMUM |
| FEATURES PROVIDED | HERMETICALLY SEALED CASE |
| (NON-CORE DATA) SPECIFICATION/STANDARD DATA | 80131-RELEASE2663 PROFESSIONAL/INDUSTRIAL ASSOCIATION SPECIFICATION |
