5985-00-248-2974 An item specifically designed for mechanically or electronically positioning one or more radio frequency transmission line sections so as to couple it or them to other sections in a radio frequency transmission line system. The switching function may be operated by a manual actuator, an electromechanical actuator or by means of an arrangement of semiconductors and passive circuit devices. Excludes RELAY, (as modified).202593000005985000000
Part Alternates: 0700297002, 07-00297-002, 72C861001, 72C861-001, 810C30100, 810C3010010, 810C30100-10 , 5985-00-248-2974, 00-248-2974, 5985002482974, 002482974
Electrical and Electronic Equipment Components | Antennas, Waveguides, and Related Equipment
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 19 FEB 1969 | 00-248-2974 | 05298 ( SWITCH, RADIO FREQUENCY TRANSMISSION LINE ) |
Drawings & Photos | NSN 5985-00-248-2974
Cross Reference | NSN 5985-00-248-2974
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 07-00297-002 | 00724 | RAYTHEON COMPANY DBA RAYTHEON |
| 72C861-001 | 04660 | AIL SYSTEMS INC SUB OF EATON CORP |
| 810C30100 | 00471 | DOW-KEY MICROWAVE CORPORATION |
| 810C30100 | 50140 | K&L MICROWAVE, INC. |
| 810C30100 | 82152 | L-3 COMMUNICATIONS CORPORATION DBA DATRON ADVANCED TECHNOLOGIES |
| 810C30100-10 | 00471 | DOW-KEY MICROWAVE CORPORATION |
Request a Quote
Comments | What our customers are saying...
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
NSNs for Compare ( up to 4 ): Add 5985-00-248-2974
Related Products | NSN 5985-00-248-2974
5985-00-248-3613, 5985-00-248-3617, 5985-00-248-4978, 5985-00-248-8805, 5985-00-248-8850
Technical Data | NSN 5985-00-248-2974
| Characteristic | Specifications |
|---|---|
| ACTUATOR OPERATING METHOD | RELAY |
| ACTUATOR CURRENT TYPE AND RATING IN AMPS | 0.8 DC MAXIMUM |
| ACTUATOR VOLTAGE IN VOLTS | 18.0 MINIMUM AND 30.0 MAXIMUM |
| SWITCH TYPE | NONTRANSFER |
| POLE QUANTITY | 1 |
| THROW QUANTITY | 2 |
| COUPLING POSITION QUANTITY | 3 |
| TERMINAL TYPE AND QUANTITY | 3 RECEPTACLE, COAXIAL AND 5 TAB, SOLDER LUG |
| COAXIAL CONNECTOR SERIES DESIGNATION | TNC |
| CONNECTOR END DESIGN | FEMALE |
| SWITCH OPERATION SEQUENCE | BREAKS BEFORE MAKES |
| SWITCHING TIME | 20.0 MILLISECONDS |
| SWITCH RETURN MECHANISM TYPE | FAIL-SAFE |
| BODY STYLE | 69B RECTANGULAR |
| OVERALL LENGTH | 2.070 INCHES NOMINAL |
| OVERALL HEIGHT | 2.970 INCHES MAXIMUM |
| OVERALL WIDTH | 1.090 INCHES MAXIMUM |
| MOUNTING FACILITY TYPE AND QUANTITY | 2 UNTHREADED HOLE |
| UNTHREADED MOUNTING HOLE DIAMETER | 0.203 INCHES NOMINAL |
| MOUNTING FACILITY PATTERN | TWO POSITION IN-LINE SINGLE MOUNTING FACILITY PATTERN |
| DISTANCE BETWEEN MOUNTING FACILITY CENTERS | 0.885 INCHES NOMINAL SINGLE MOUNTING FACILITY PATTERN |
| SPECIAL FEATURES | ACTUATING LIFE 100,000 OPERATIONS MINIMUM |
| III OPERATING TEMP RANGE | -54.0 TO 85.0 DEG CELSIUS |
| III END ITEM IDENTIFICATION | 5895-00-775-3200 ANTENNA,COUNTER AS-2044/ALQ-86 |
