Product Details | DELAY LINE
5999-00-482-7204 An item which provides a predetermined delay to an electrical pulse, while maintaining substantially the same waveform. The delay is obtained by means of a real or artificial transmission line or equivalent device. The equivalent device may be acoustic, distributive, lumped constant, magnetic solid state, or surface acoustical wave type. See also ATTENUATOR, (as modified); TRANSFORMER, (as modified); and OSCILLATOR, PULSE DELAY.
Part Alternates: M7307, 1040491, 104049-1, 5999-00-482-7204, 00-482-7204, 5999004827204, 004827204
Electrical and Electronic Equipment Components | Miscellaneous Electrical and Electronic Components
