NSN 6645-01-175-3407 60M8001, 8601, 01-175-3407

Product Details | SEQUENTIAL TIMER


6645-01-175-3407 An item which actuates included electrical contacts and/or switches in an orderly succession, and at a predetermined interval(s) for the purpose of controlling the operation of another electrical device(s). May have provision for manually establishing an operational sequence or cycle. See also RELAY, MOTOR DRIVEN; TIMER, INTERVAL; KEYER (as modified); CHRONOMETER, MAKE-BREAK CIRCUIT and INTERVALOMETER (as modified).

Part Alternates: 60M8001, 8601, 6645-01-175-3407, 01-175-3407, 6645011753407, 011753407

Instruments and Laboratory Equipment | Time Measuring Instruments

Supply Group (FSG) NSN Assign. NIIN
66 30 MAR 1984 01-175-3407

Drawings & Photos | NSN 6645-01-175-3407




Cross Reference | NSN 6645-01-175-3407


Part Number Cage Code Manufacturer
60M8001 05468 TORK INC
8601 05468 TORK INC

Request a Quote



Comments | What our customers are saying...


Honeywell

Thank you very much for the excellent service and professional customer care.

Ernie G. Honeywell
Raytheon

The service was excellent. I can think of no improvements to date that you can make regarding internet sales.

John L. Raytheon
General Dynamics

The representative for WBParts was efficient & handled our request in a timely & professional manner.

Karen G. General Dynamics
US Airforce

Tried two other sources, neither of them responded, was all done online, never spoke to anyone.

Rex S. US Airforce
NASA

The response is quick and the price is often very good. We are completely satisfied.


NSNs for Compare ( up to 4 ): Add 6645-01-175-3407


Technical Data | NSN 6645-01-175-3407


Characteristic Specifications
TIMER TYPE ELECTRICAL
CONTROL TYPE SWITCH
DIAL SIZE 3.250 IN. DIA
CASE MATERIAL STEEL
OVERALL HEIGHT 8.000 INCHES NOMINAL
OVERALL WIDTH 4.750 INCHES NOMINAL
OVERALL DEPTH 3.000 INCHES NOMINAL
SPECIAL FEATURES BATTERY CHARGER TIMER;60 MINUTE DUTY CYCLE,DAIL PROVIDES 1 TO 30 ON-OFF OPERATIONS PER HR WITH 1 MINUTE MIN. ON/OFF SETTINGS,10 AMPS,120 V,SPDT SWITCH,10 AMPS,NOM 240 VAC,3/4 HP AT 120 VAC,1-1/2 HP AT 240 VAC,TIMING MOTOR SELF-STARTING,120 OR 240 V,60 HZ,3 WATTS POWER CONSUMPTION;FINISH-BEIGE BAKED EPOXY ENAMEL;LOCKABLE HASP
III END ITEM IDENTIFICATION 175 KW,219 KVA ENGINE GENERATOR,CONTRACT NUMBER FA70AC1017-3H
MANUFACTURERS CODE 05468
DESIGN CONTROL REFERENCE 8601

Restrictions/Controls & Freight Information | NSN 6645-01-175-3407


Category Code Description
Hazardous Material Indicator CodeNThere is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials
Demilitarization Code:ANon-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Precious Metals Indicator Code:UPrecious metal type is unknown
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Category Code Description
No Freight Information
