NSN 6685-01-417-8777 DLT01MAPM1012, 01-417-8777, 014178777
Product Details | DIAL INDICATING PRESSURE GAGE
6685-01-417-8777 An instrument designed to measure air, gas, fluid, and vapor pressure by means of an internal pressure sensitive element (bellows, bourdon tube, transducer/transmitter and the like) which transmits energy, by direct linkage, to the indicating pointer of a scale or a digital display, calibrated in units of pressure. It may include a temperature equivalent scale. For items that do not have an internal pressure sensitive element see INDICATOR, PRESSURE.205138600004220000042400027Safety and Rescue Equipment66200018Engine Instruments66850073Pressure, Temperature, and Humidity Measuring and Controlling Instruments
Part Alternates: DLT01MAPM1012, 6685-01-417-8777, 01-417-8777, 6685014178777, 014178777
Instruments and Laboratory Equipment | Pressure, Temperature, and Humidity Measuring and Controlling Instruments
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 66 | 16 AUG 1995 | 01-417-8777 | 07428 ( GAGE, PRESSURE, DIAL INDICATING ) |
