Product Details | ANNULAR BALL BEARING
3110-00-922-8516 A cylindrical device in which the inner or outer ring turns upon a single or double row of hardened balls which roll easily between the two rings, thus minimizing friction. For items with faces specially ground for duplex mounting see BEARING, BALL, DUPLEX. Excludes BEARING, BALL, AIRFRAME.
Part Alternates: M17931G034, M17931-G034, M17931G034NT, M17931-G034NT, M17934G034, M17934-G034, A-215-196 ITEM 22, A-215-196 ITEM 22NT, A215196ITEM22, A215196ITEM22NT, H-2650-1220GP12 ITEM 23, H26501220GP12ITEM23, H-2650-1220GP18 ITEM 23, H26501220GP18ITEM23, H-2650-1220GP19 ITEM 23, H26501220GP19ITEM23, H26501220PC23, H2650-1220PC23, H-2650-1285GP1- ITEM 26, H-2650-1285GP10 ITEM 26, H26501285GP10ITEM26, H-2650-1285GP11 ITEM 26, H26501285GP11ITEM26, H26501285GP1ITEM26, H-2650-1285GP5 ITEM 26, H26501285GP5ITEM26, H26501285PC26, H2650-1285PC26, H-2650-1300GP3 ITEM 28, H26501300GP3ITEM28, H26501540PC23, H2650-1540PC23, ESB05805, ESB058-05, ESB05805NT, ESB058-05NT, MILB17931C, 63072RSW1B, 6307-2RSW1B, 6307UUE100, 79999121, 79999121NT, 996077077V4, 99607-7077V4, 26501005PC26, 2650-1005PC26, 26501015PC26, 2650-1015PC26, 26501020PC130, 2650-1020PC130, 26501030PC28, 2650-1030PC28, 26501045PC23, 2650-1045PC23, 26501060PC23, 2650-1060PC23, 26501085PC26, 2650-1085PC26, 26501100PC23, 2650-1100PC23, 26501165PC26, 2650-1165PC26, 26501220PC23, 2650-1220PC23, 26501260PC19, 2650-1260PC19, 26501280PC26, 2650-1280PC26, 26501285PC26, 2650-1285PC26, 26501455PC28, 2650-1455PC28, 2650-2240GP1 ITEM 27, 26502240GP1ITEM27, 2650-2240GP3 ITEM 27, 26502240GP3ITEM27, 2650-2240GP4 ITEM 27, 26502240GP4ITEM27, 2650-2260GP1 ITEM 27, 26502260GP1ITEM27, 2650-2260GP2 ITEM 27, 26502260GP2ITEM27, 2650-2265GP1 ITEM 40, 26502265GP1ITEM40, 2650-2265GP2 ITEM 40, 26502265GP2ITEM40, 2650-2275GP2 ITEM 52, 26502275GP2ITEM52, 2650-2715 GP6 ITEM 44, 26502715GP6ITEM44, 2650-2775GP3 ITEM 44, 26502775GP3ITEM44, 2650-2775GP5 ITEM 44, 26502775GP5ITEM44, 2650-2775GP6 ITEM 44, 26502775GP6ITEM44, 2650-2975 ITEM 26, 26502975ITEM26, 2650321546, 2650-3215-46, 2650321546NT, 2650-3215-46NT, 2650-3225 ITEM 46, 26503225ITEM46, 2650-3230 ITEM 36, 26503230ITEM36, 2650330046, 2650-3300-46, 2650330046NT, 2650-3300-46NT, 26503305046, 2650-3305-046, 2650-3375GP1 ITEM 46, 26503375GP1ITEM46, 307SABEC5, 307S-ABEC-5, 307SABEC5NT, 307S-ABEC-5NT, 307SZZNT3, 3110-00-922-8516, 00-922-8516, 3110009228516, 009228516
Bearings | Bearings, Antifriction, Unmounted
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 31 | 09 JAN 1966 | 00-922-8516 | 00014 ( BEARING, BALL, ANNULAR ) |
Drawings & Photos | NSN 3110-00-922-8516
Demand History | NSN 3110-00-922-8516
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 3110-00-922-8516 | 2022-11-07 | 0 | NECO |
| 3110-00-922-8516 | 2022-10-14 | 0 | NECO |
| 3110-00-922-8516 | 2021-01-29 | 0 | NECO |
| 3110-00-922-8516 | 2019-04-06 | 227 | NECO |
| 3110-00-922-8516 | 2017-12-22 | 130 | NECO |
| 3110-00-922-8516 | 2017-07-07 | 288 | NECO |
| 3110-00-922-8516 | 2017-06-01 | 1 | US |
| 3110-00-922-8516 | 2017-05-23 | 233 | NECO |
| 3110-00-922-8516 | 2013-12-31 | 68 | NECO |
| 3110-00-922-8516 | 2012-11-27 | 323 | NECO |
| 3110-00-922-8516 | 2011-11-10 | 39 | NECO |
| 3110-00-922-8516 | 2011-05-27 | 39 | NECO |
Cross Reference | NSN 3110-00-922-8516
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 2650-1005PC26 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| 2650-1015PC26 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| 2650-1020PC130 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| 2650-1030PC28 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| 2650-1045PC23 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| 2650-1060PC23 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| 2650-1085PC26 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| 2650-1100PC23 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| 2650-1165PC26 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| 2650-1220PC23 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| 2650-1260PC19 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| 2650-1280PC26 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| 2650-1285PC26 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| 2650-1285PC26 | 96169 | ELECTRIC BOAT CORPORATION |
| 2650-1455PC28 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| 2650-2240GP1 ITEM 27 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| 2650-2240GP1 ITEM 27 | 96169 | ELECTRIC BOAT CORPORATION |
| 2650-2240GP3 ITEM 27 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| 2650-2240GP3 ITEM 27 | 96169 | ELECTRIC BOAT CORPORATION |
| 2650-2240GP4 ITEM 27 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| 2650-2240GP4 ITEM 27 | 96169 | ELECTRIC BOAT CORPORATION |
| 2650-2260GP1 ITEM 27 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| 2650-2260GP1 ITEM 27 | 96169 | ELECTRIC BOAT CORPORATION |
| 2650-2260GP2 ITEM 27 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| 2650-2260GP2 ITEM 27 | 96169 | ELECTRIC BOAT CORPORATION |
| 2650-2265GP1 ITEM 40 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| 2650-2265GP1 ITEM 40 | 96169 | ELECTRIC BOAT CORPORATION |
| 2650-2265GP2 ITEM 40 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| 2650-2265GP2 ITEM 40 | 96169 | ELECTRIC BOAT CORPORATION |
| 2650-2275GP2 ITEM 52 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| 2650-2275GP2 ITEM 52 | 96169 | ELECTRIC BOAT CORPORATION |
| 2650-2715 GP6 ITEM 44 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| 2650-2715 GP6 ITEM 44 | 96169 | ELECTRIC BOAT CORPORATION |
| 2650-2775GP3 ITEM 44 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| 2650-2775GP3 ITEM 44 | 96169 | ELECTRIC BOAT CORPORATION |
| 2650-2775GP5 ITEM 44 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| 2650-2775GP5 ITEM 44 | 96169 | ELECTRIC BOAT CORPORATION |
| 2650-2775GP6 ITEM 44 | 95401 | EARL JOHN A INC QUAKER MAINTENANCE CO INC DIV |
| 2650-2775GP6 ITEM 44 | 96169 | ELECTRIC BOAT CORPORATION |
| 2650-2975 ITEM 26 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| 2650-2975 ITEM 26 | 96169 | ELECTRIC BOAT CORPORATION |
| 2650-3215-46 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| 2650-3215-46NT | 03950 | NAVAL INVENTORY CONTROL POINT MECHANICSBURG |
| 2650-3225 ITEM 46 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| 2650-3225 ITEM 46 | 96169 | ELECTRIC BOAT CORPORATION |
| 2650-3230 ITEM 36 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| 2650-3230 ITEM 36 | 96169 | ELECTRIC BOAT CORPORATION |
| 2650-3300-46 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| 2650-3300-46NT | 03950 | NAVAL INVENTORY CONTROL POINT MECHANICSBURG |
| 2650-3305-046 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| 2650-3375GP1 ITEM 46 | 51802 | HANSOME ENERGY SYSTEMS INC |
| 2650-3375GP1 ITEM 46 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| 2650-3375GP1 ITEM 46 | 96169 | ELECTRIC BOAT CORPORATION |
| 307S-ABEC-5 | 78189 | ITW SHAKEPROOF AUTOMOTIVE PRODUCTS |
| 307S-ABEC-5NT | 03950 | NAVAL INVENTORY CONTROL POINT MECHANICSBURG |
| 307SZZNT3 | 38443 | SKF USA INC DBA SKF AEROENGINE NORTH AMERICA |
| 6307-2RSW1B | 52676 | SKF USA INC. |
| 6307UUE100 | 53035 | NSK CORP BEARING DIV |
| 79999121 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| 79999121 | 96169 | ELECTRIC BOAT CORPORATION |
| 79999121NT | 03950 | NAVAL INVENTORY CONTROL POINT MECHANICSBURG |
| 99607-7077V4 | 43334 | GENERAL MOTORS CORP DELCO MORAINE NDH DIV |
| A-215-196 ITEM 22 | 51802 | HANSOME ENERGY SYSTEMS INC |
| A-215-196 ITEM 22NT | 03950 | NAVAL INVENTORY CONTROL POINT MECHANICSBURG |
| ESB058-05 | 51802 | HANSOME ENERGY SYSTEMS INC |
| ESB058-05NT | 03950 | NAVAL INVENTORY CONTROL POINT MECHANICSBURG |
| H-2650-1220GP12 ITEM 23 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| H-2650-1220GP12 ITEM 23 | 96169 | ELECTRIC BOAT CORPORATION |
| H-2650-1220GP18 ITEM 23 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| H-2650-1220GP18 ITEM 23 | 96169 | ELECTRIC BOAT CORPORATION |
| H-2650-1220GP19 ITEM 23 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| H-2650-1220GP19 ITEM 23 | 96169 | ELECTRIC BOAT CORPORATION |
| H-2650-1285GP1- ITEM 26 | 96169 | ELECTRIC BOAT CORPORATION |
| H-2650-1285GP10 ITEM 26 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| H-2650-1285GP10 ITEM 26 | 96169 | ELECTRIC BOAT CORPORATION |
| H-2650-1285GP11 ITEM 26 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| H-2650-1285GP11 ITEM 26 | 96169 | ELECTRIC BOAT CORPORATION |
| H-2650-1285GP5 ITEM 26 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| H-2650-1285GP5 ITEM 26 | 96169 | ELECTRIC BOAT CORPORATION |
| H-2650-1300GP3 ITEM 28 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| H-2650-1300GP3 ITEM 28 | 96169 | ELECTRIC BOAT CORPORATION |
| H2650-1220PC23 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| H2650-1220PC23 | 96169 | ELECTRIC BOAT CORPORATION |
| H2650-1285PC26 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| H2650-1285PC26 | 96169 | ELECTRIC BOAT CORPORATION |
| H2650-1540PC23 | 95402 | ELECTRIC BOAT CORP DBA ELECTRO DYNAMIC |
| H2650-1540PC23 | 96169 | ELECTRIC BOAT CORPORATION |
| M17931-G034 | 21335 | TIMKEN COMPANY, THE DIV TIMKEN AEROSPACE |
| M17931-G034 | 70854 | BARDEN CORPORATION, THE DIV BARDEN PRECISION BEARINGS |
| M17931-G034 | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| M17931-G034NT | 03950 | NAVAL INVENTORY CONTROL POINT MECHANICSBURG |
| M17934-G034 | 70854 | BARDEN CORPORATION, THE DIV BARDEN PRECISION BEARINGS |
| MILB17931C | 23803 | N T N BEARING CORP OF AMERICA |
Request a Quote
Comments | What our customers are saying...
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Related Products | NSN 3110-00-922-8516
3110-00-922-8758, 3110-00-922-9938, 3110-00-923-0447, 3110-00-923-0623, 3110-00-923-0887
Technical Data | NSN 3110-00-922-8516
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL BALL STEEL INNER RING STEEL OUTER RING STEEL RETAINER RUBBER SYNTHETIC SEAL |
| STYLE DESIGNATOR | 10A NON-LOADING GROOVE, NON-SEPARABLE |
| OVERALL WIDTH | 0.8240 INCHES MINIMUM AND 0.8268 INCHES MAXIMUM |
| BORE DIAMETER | 1.3778 INCHES MINIMUM AND 1.3780 INCHES MAXIMUM |
| OVERALL OUTSIDE DIAMETER | 2.8344 INCHES MINIMUM AND 2.8346 INCHES MAXIMUM |
| LUBRICATION MATERIAL | GREASE |
| LUBRICATION MATERIAL DOCUMENT AND CLASSIFICATION | MIL-G-18709 MIL SPEC SINGLE MATERIAL RESPONSE |
| BORE SHAPE | STRAIGHT |
| SURFACE FINISH | GROUND |
| RETAINER FABRICATION METHOD | PRESSED |
| SEAL QUANTITY | 2 |
| BEARING SEAL TYPE | CONTACT |
| LOAD DIRECTION | RADIAL |
| INTERNAL FIT-UP DESIGNATION | STANDARD |
| INTERNAL CLEARANCE | 0.0005 INCHES MINIMUM RADIAL AND 0.0008 INCHES MAXIMUM RADIAL |
| NONDEFINITIVE SPEC/STD DATA | 111 TYPE |
| DEPARTURE FROM CITED DESIGNATOR | TESTED FOR QUIET OPERATION APPLICABLE TO SUBMARINE USAGE |
| CRITICALITY CODE JUSTIFICATION | ZZZX |
| MANUFACTURERS CODE | 81349 |
| NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | M17931-G034 |
Restrictions/Controls & Freight Information | NSN 3110-00-922-8516
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | X | more than 60 months |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | D | Munitions List Item or Commerce Control List Item. Demilitarization required. Total destruction of the item and components so as to preclude restoration or repair to a usable condition by melting, cutting, tearing, scratching, crushing, breaking, punching, neutralizing, etc. (As an alternate, burial or deep water dumping may be used when coordinated with the DoD Demilitarization Program Office.) |
| Controlled Inventory Item Code: | 7 | NON-SENSITIVE (SRC-N/A) - UNCLASSIFIED AA&E: OR ITEMS ASSIGNED A DEMILITARIZATION CODE OTHER THAN A, B, Q, OR P FOR WHICH ANOTHER CIIC IS INAPPROPRIATE. (NOTE: THE LOSS, THEFT, UNLAWFUL DISPOSITION, AND/OR RECOVERY OF AN ITEM WITH CIIC 7 WILL BE INVESTIGATED IN ACCORDANCE WITH DOD-4000-25-2-M AND DOD 7200.14-R, VOLUME 12, CHAPTER 7). |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | Y | The item does not have a nuclear hardened feature but does have other critical feature(s) such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 114820 | BEARINGS/BUSHINGS NOI BALL/ROLLER |
| Less than car load rating | P | 77.5 |
| Less than truck load rating | P | 77.5 |
| Water commodity Code | 742 | unknown |
| Originating Activity Code | HD | Naval Inventory Control Point Mechanicsburg, PA 17055-0788 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 3110-00-922-8516
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 1H | Consumable material assigned to NAVICP MECH for inventory management Naval Inventory Control Point, Mechanicsburg |
| Special Material ID | NT | Annular Ball Bearing for quiet operation application to submarine usage, (Noise Test Bearings) |
| Special Material Content | 9 | Non-Hazardous or Non-Sensitive Item, does not require hazardous or special handling, packaging or precautions |
| Source of Supply | NRP | NAVICP-ERP 700 Robbins Avenue Philadelphia, PA 19111-5098 |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Reparability | D | Field Level Reparables |
| Acquisition Advice Codes | D | DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures. |
| Controlled Item Code | 7 | NON-SENSITIVE (SRC-N/A) - UNCLASSIFIED AA&E: OR ITEMS ASSIGNED A DEMILITARIZATION CODE OTHER THAN A, B, Q, OR P FOR WHICH ANOTHER CIIC IS INAPPROPRIATE. (NOTE: THE LOSS, THEFT, UNLAWFUL DISPOSITION, AND/OR RECOVERY OF AN ITEM WITH CIIC 7 WILL BE INVESTIGATED IN ACCORDANCE WITH DOD-4000-25-2-M AND DOD 7200.14-R, VOLUME 12, CHAPTER 7). |
| Shelf Life Code | X | more than 60 months | Purchasing | QTY UOM |
