NSN 3120-01-171-4932 735408, 01-171-4932, 011714932
Product Details | SLEEVE BEARING
3120-01-171-4932 A tubular shaped item with or without flange(s) designed to reduce friction and carry a kinetic load on the surface(s) parallel to the axis of the bore. It must have a visible or detectable means of lubrication or be self-lubricated. The over all length must exceed 25 percent of the outside diameter or the shortest distance between peripheral flats of the body, except for straight tubular (without flange or shoulder) items having a bearing surface(s) parallel to the axis of the bore only. Includes items which are divided into two or more segments which include 180 degrees (3.141 radians) or less of the bearing periphery. See also BUSHING, SLEEVE; SPACER, SLEEVE; and WASHER (as modified). Excludes PIN, HOLLOW.
Part Alternates: 735408, 3120-01-171-4932, 01-171-4932, 3120011714932, 011714932
Bearings | Bearings, Plain, Unmounted
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 31 | 08 FEB 1984 | 01-171-4932 | 13205 ( BEARING, SLEEVE ) |
Drawings & Photos | NSN 3120-01-171-4932
Demand History | NSN 3120-01-171-4932
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 3120-01-171-4932 | 2010-07-202 | 8 | DIBBS |
| 3120-01-171-4932 | 2009-12-337 | 8 | DIBBS |
| 3120-01-171-4932 | 2009-11-306 | 1 | DIBBS |
| 3120-01-171-4932 | 2009-09-267 | 1 | DIBBS |
| 3120-01-171-4932 | 2007-03-67 | 2 | DIBBS |
Cross Reference | NSN 3120-01-171-4932
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 735408 | 99167 | HAMILTON SUNDSTRAND CORPORATION |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 3120-01-171-4932
Related Products | NSN 3120-01-171-4932
Technical Data | NSN 3120-01-171-4932
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL COMP E52100 OVERALL |
| HARDNESS RATING | 58.0 ROCKWELL C MINIMUM AND 62.0 ROCKWELL C MAXIMUM OVERALL |
| STYLE DESIGNATOR | 18C-3 SOLID INTERNAL FLANGE AT BOTH ENDS |
| OVERALL LENGTH | 1.5890 INCHES MINIMUM AND 1.5990 INCHES MAXIMUM |
| BODY OUTSIDE DIAMETER | 2.1310 INCHES MINIMUM AND 2.1510 INCHES MAXIMUM |
| BODY INSIDE DIAMETER | 1.8910 INCHES MINIMUM AND 1.9210 INCHES MAXIMUM |
| LEFT INTERNAL FLANGE HOLE DIAMETER | 1.8437 INCHES MINIMUM AND 1.8442 INCHES MAXIMUM |
| RIGHT INTERNAL FLANGE HOLE DIAMETER | 1.8460 INCHES MINIMUM AND 1.8465 INCHES MAXIMUM |
| LEFT INTERNAL FLANGE WIDTH | 0.4200 INCHES MINIMUM AND 0.4800 INCHES MAXIMUM |
| RIGHT INTERNAL FLANGE WIDTH | 0.4240 INCHES NOMINAL |
| LEFT FLANGE OUTSIDE DIAMETER | 2.5300 INCHES MINIMUM AND 2.5400 INCHES MAXIMUM |
| RIGHT FLANGE OUTSIDE DIAMETER | 2.1800 INCHES MINIMUM AND 2.1900 INCHES MAXIMUM |
| LEFT FLANGE WIDTH | 0.4010 INCHES MINIMUM AND 0.4110 INCHES MAXIMUM |
| RIGHT FLANGE WIDTH | 0.5050 INCHES NOMINAL |
| CORNER SHAPE | SQUARE OUTSIDE LEFT CORNER SQUARE OUTSIDE RIGHT CORNER CHAMFERED INSIDE RIGHT CORNER UNDERCUT INSIDE LEFT CORNER SQUARE LEFT FLANGE OUTSIDE RIGHT CORNER ROUND LEFT FLANGE BODY CORNER SQUARE RIGHT FLANGE OUTSIDE LEFT CORNER ROUND RIGHT FLANGE BODY CORNER |
| (NON-CORE DATA) CHAMFER LENGTH | 0.034641 INCHES NOMINAL |
| (NON-CORE DATA) CHAMFER ANGLE | 30.0 DEGREES NOMINAL |
| (NON-CORE DATA) RADIUS | 0.0620 INCHES NOMINAL 0.0620 INCHES NOMINAL |
| (NON-CORE DATA) UNDERCUT WIDTH | 0.0740 INCHES NOMINAL |
| (NON-CORE DATA) UNDERCUT DEPTH | 0.12515 INCHES NOMINAL |
| MANUFACTURERS CODE | 99167 |
| DESIGN CONTROL REFERENCE | 735408 |
