NSN 5305-01-171-6509 NACB3ONE626, NACB3ONE6-26 , NAS660626
Product Details | PANEL SCREW ASSEMBLY
5305-01-171-6509 A headed, threaded fastening device over which may be assembled; (1) a stand-off; (2) a flanged bushing with washer(s) and/or a shouldered bushing without a flange, or it may have an internally threaded sleeve that is an integral part of the screw; a washer and an externally thread self-locking bushing that is driven by an inserted driver. Attached to panel by threaded bushing or by flaring end of stand-off, or bushing. Used in conjunction with a speed nut, nut plate, or driven into a threaded hole in the item that the panel is fastened to. May be spring loaded.
Part Alternates: NACB3ONE626, NACB3ONE6-26 , NAS660626, NAS6606-26 , BACB30NE626, BACB30NE6-26 , BACB30NF626, BACB30NF6-26 , CA28080089HS, CA28080-08-9HS, CA28409HS, CA2840-9HS, 10116084 , 5189469001, 5189469-001, 0098LLTJ22591, 61334841, 6133484-1, 0098-LL-TJ2-2591, 5305-01-171-6509, 01-171-6509, 5305011716509, 011716509
Hardware and Abrasives | Screws
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 11 FEB 1984 | 01-171-6509 | 33044 ( SCREW ASSEMBLY, PANEL ) |
Drawings & Photos | NSN 5305-01-171-6509
Demand History | NSN 5305-01-171-6509
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5305-01-171-6509 | 2019-08-218 | 85 | US |
| CA28080-08-9HS | 2019-04-93 | 59 | DIBBS |
| FTK7016HS-8-9A | 2019-04-93 | 59 | DIBBS |
| CA28080-08-9HS | 2019-03-62 | 59 | DIBBS |
| FTK7016HS-8-9A | 2019-03-62 | 59 | DIBBS |
| 5305-01-171-6509 | 2018-12-348 | 20 | US |
| CA28080089HS | 2018-02-45 | 4 | United States |
| 5305-01-171-6509 | 2017-03-60 | 32 | DIBBS |
| 5305-01-171-6509 | 2017-02-52 | 32 | DIBBS |
| NAS6606-26 | 2014-12-357 | 72 | Australia |
| NAS6606-26 | 2014-08-232 | 136 | Australia |
| NAS6606-26 | 2014-08-232 | 136 | United States |
| NAS6606-26 | 2014-08-232 | 136 | United States |
| NAS6606-26 | 2014-08-227 | 136 | Australia |
| NAS660626 | 2014-07-211 | 24 | Australia |
| NAS6606-26 | 2014-06-157 | 50 | United States |
| 5305-01-171-6509 | 2014-04-92 | 57 | DIBBS |
| 5305-01-171-6509 | 2014-03-77 | 57 | DIBBS |
| CA28080089HS | 2011-05-138 | 30 | United States |
| CA28080089HS | 2011-05-122 | 30 | US |
| 5305-01-171-6509 | 2010-01-21 | 82 | DIBBS |
| 5305-01-171-6509 | 2009-06-154 | 73 | DIBBS |
| 5305-01-171-6509 | 2009-05-139 | 73 | DIBBS |
| CA28080089HS | 2009-03-82 | 5 | US |
| 5305-01-171-6509 | 2009-02-47 | 25 | DIBBS |
| 5305-01-171-6509 | 2008-09-251 | 2 | DIBBS |
| 5305-01-171-6509 | 2008-06-164 | 1 | DIBBS |
Cross Reference | NSN 5305-01-171-6509
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 0098-LL-TJ2-2591 | 53711 | NAVAL SEA SYSTEMS COMMAND |
| 5189469-001 | 53711 | NAVAL SEA SYSTEMS COMMAND |
| 6133484-1 | 03640 | LOCKHEED MARTIN CORPORATION DBA LOCKHEED MARTIN |
| CA28080-08-9HS | 29372 | ALCOA GLOBAL FASTENERS, INC. DBA ALCOA FASTENING SYSTEMS |
| CA2840-9HS | 29372 | ALCOA GLOBAL FASTENERS, INC. DBA ALCOA FASTENING SYSTEMS |
| FTK7016HS-8-9A | 58794 | FASTENER TECHNOLOGY CORP. |
