NSN 5305-01-620-5062 HS6116HS0200, FTD7201HS0200 , 01-620-5062

Product Details | PANEL SCREW ASSEMBLY

5305-01-620-5062 A headed, threaded fastening device over which may be assembled; (1) a stand-off; (2) a flanged bushing with washer(s) and/or a shouldered bushing without a flange, or it may have an internally threaded sleeve that is an integral part of the screw; a washer and an externally thread self-locking bushing that is driven by an inserted driver. Attached to panel by threaded bushing or by flaring end of stand-off, or bushing. Used in conjunction with a speed nut, nut plate, or driven into a threaded hole in the item that the panel is fastened to. May be spring loaded.

Part Alternates: HS6116HS0200, FTD7201HS0200 , 5305-01-620-5062, 01-620-5062, 5305016205062, 016205062
