NSN 5950-00-079-6518 MS28775148, MS28775-148 , MS28775148ES
Product Details | RADIO FREQUENCY COIL
5950-00-079-6518 An item consisting of a partial turn as one or more turns of wire or other conductive material which constitutes one continuous untapped winding. It may be wound or formed in other than a circular manner and may be self-supporting, requiring no coil form. It is specifically designed to furnish inductive reactance in a circuit carrying radio frequency current ranging from 20 kilohertz (kilocycles) and above. It may include tuning devices, integral resistors and capacitors; however, excludes FILTER (as modified). The coil has only two electrical terminals. For items having tapped winding or more than one winding - see TRANSFORMER, RADIO FREQUENCY. For coils wound on resistors, which are designed to be inserted in the circuit of a radio frequency stage to suppress high frequency parasitic oscillations, see SUPPRESSOR, PARASITIC.
Part Alternates: MS28775148, MS28775-148 , MS28775148ES, MS28775-148ES , M4020853, M402085-3, N0304 2-148 , N03042148, PRP568148406770, PRP568-148-4067-70 , WEE-WEE-2.7, WEEWEE27, 135-104-018, 1376-23-172 , 2-148 N304-75 , 2148N30475, 2300-79078 , 25704281200150, 25704-281200-15-0 , 40139470706, 4013947-0706, 4398602-96 , 5950-00-079-6518, 00-079-6518, 5950000796518, 000796518, 439860296, 135104018, 137623172, 230079078
Electrical and Electronic Equipment Components | Coils and Transformers
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 11 DEC 1967 | 00-079-6518 | 06338 ( COIL, RADIO FREQUENCY ) |
Drawings & Photos | NSN 5950-00-079-6518
Demand History | NSN 5950-00-079-6518
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| MS28775148 | 2019-11-316 | 15 | United States |
| MS28775-148 | 2011-11-313 | 50 | South Korea |
Cross Reference | NSN 5950-00-079-6518
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5950-00-079-6518
Technical Data | NSN 5950-00-079-6518
| Characteristic | Specifications |
|---|---|
| TERMINAL TYPE AND QUANTITY | 2 WIRE LEAD |
| RATING METHOD | ELECTRICAL SINGLE COMPONENT SINGLE WINDING |
| WINDING CONDUCTOR SIZE | 0.02010 INCHES AMERICAN WIRE GAGE SINGLE COMPONENT SINGLE WINDING |
| WINDING OPERATING CURRENT | 935.0 MILLIAMPERES DC MAXIMUM SINGLE COMPONENT SINGLE WINDING |
| DC RESISTANCE RATING IN OHMS | 0.381 SINGLE COMPONENT SINGLE WINDING |
| INDUCTANCE RATING | 2.70 MICROHENRIES NOMINAL SINGLE COMPONENT SINGLE WINDING |
| QUALITY FACTOR | 38 MINIMUM SINGLE COMPONENT SINGLE WINDING |
| (NON-CORE DATA) FREQUENCY AT WHICH INDUCTANCE AND QUALITY FACTOR APPLIES | 7.9 MEGAHERTZ SINGLE COMPONENT SINGLE WINDING |
| (NON-CORE DATA) MINIMUM SELF-RESONANT FREQUENCY | 106.0 MEGAHERTZ SINGLE COMPONENT |
| COIL FORM TYPE | SOLID SINGLE COMPONENT |
| CORE CONSTRUCTION | S0LID SINGLE COMPONENT |
| MOUNTING METHOD | TERMINAL SINGLE GROUP |
| INCLOSURE TYPE | FULLY INCLOSED |
| BODY LENGTH | 0.335 INCHES MAXIMUM |
| OVERALL DIAMETER | 0.133 INCHES MAXIMUM |
| RELIABILITY INDICATOR | NOT ESTABLISHED |
| III MAXIMUM OPERATING TEMP | 125.0 DEG CELSIUS |
| (NON-CORE DATA) UNPACKAGED UNIT WEIGHT | 0.5 GRAMS |
| (NON-CORE DATA) CUBIC MEASURE | 0.0041 CUBIC INCHES |
Restrictions/Controls & Freight Information | NSN 5950-00-079-6518
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | Y | 180 months |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 194120 | WASHERS/GASKETS/PCKG DVCS NOI |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 596 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
