Product Details | RADIO FREQUENCY REFLECTION ISOLATOR
5985-00-284-3354 A device which allows radio frequency energy to pass in one direction with very little power loss, but blocks the flow of energy in the other direction by means of multiple WAVE-polarization or an integral dissipative load. It isolates frequency sensitive circuity from the effects of reflected radio frequency energy resulting from component mismatch. It usually has one or more ports terminated with coaxial connector(s) and/or waveguide flange(s); or other electrical terminations. Isolators designed for internal use in waveguide runs may consist of rods, rings, chips, strips and the like and have no ports or terminations. See also DIPLEXER; DUPLEXER. Excludes CIRCULATOR, RADIO FREQUENCY.
Part Alternates: 002843354
Communication, Detection, and Coherent Radiation Equipment | Miscellaneous Communication Equipment
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 58 | 00-284-3354 | 20347 ( ISOLATOR, RADIO FREQUENCY REFLECTION ) |
Drawings & Photos | NSN 5895-00-284-3354
Demand History | NSN 5985-00-284-3354
Request a Quote
Comments | What our customers are saying...
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Related Products | NSN 5985-00-284-3354
5895-00-284-4224, 5895-00-284-4225, 5895-00-284-4835, 5895-00-284-5985, 5895-00-284-6824
Technical Data | NSN 5985-00-284-3354
| Characteristic | Specifications |
|---|---|
| FREQUENCY RANGE RATING | 4.2 TO 4.4 GIGAHERTZ |
| OVERALL LENGTH | 2.660 INCHES NOMINAL |
| OVERALL WIDTH | 1.190 INCHES NOMINAL |
| OVERALL HEIGHT | 1.900 INCHES MINIMUM AND 2.100 INCHES MAXIMUM |
| CONNECTOR QUANTITY | 2 |
| CONTROLLING AGENCY | EPSCO INC. |
| TRADE DESIGNATION | CONNECTOR,PLUG,ELECTRICAL |
| IDENTIFYING NUMBER | 104463 DRAWING NO. |
